TOPP Kettenantrieb C30 - 230V

C30 Konsolensatz weiß im Lieferumfang enthalten

TOPP Kettenantrieb C30 - 230V

TOPP Kettenantrieb C30 - 230V

TOPP Kettenantrieb C30 - 230V

TOPP Kettenantrieb C30 - 230V

TOPP Chain drive C30 - 230V

Item no: 9977

Manufacturer number: 3A49902

Delivery time 23 - 26 Working days
Important info about the delivery time specification

€105.08 *

incl. VAT plus shipping costs

Leave your email address and stay informed about this article.

as soon as the item is back in stock

as soon as the item drops in price

as soon as the item is available as a special offer

Chain drive Topp model C30 in housing, incl. bracket and accessories for top-hung and... more

Chain drive Topp model C30 in housing, incl. bracket and accessories for top-hung and bottom-hung windows

Technical data

Supply voltage: 230V ~ 50Hz
Thrust force: 300 N
Pulling force: 300 N
Stroke (adjustable): 200 / 380 mm
Power consumption: 0,26 A
Speed: 37 mm\s
Running time: 11 s
Protection class: II (protective insulation)
Operating mode: S2- 4 min
Operating temperature: - 5°C + 50°C
Protection class: IP 30
Setting of window fastening: 15mm
Adjustment of pins on swinging brackets: 15mm
Regulation of connection to sash: not required
Parallel connection of 2 or more drives: yes
Limit switch open/close: electronic / electronic
Dimensions: 337,2x80x49 mm

Technical advice

+49 9282 48731-15
technik@bsc-technology.de

Fast delivery

... of goods in stock. Orders placed before 14:00 are usually shipped the same day.

Questions about the article

to the inquiry form

Technical data more

RWA suitable :	No
Application :	For bottom-hung windows (without restriction to 15cm), For skylight domes, For standard tilt and turn windows, Pivot window, Tilt window, Top hung window
Ambient temperature :	-5°C ...+50°C
Operating mode :	S2 - 4min
Protection class :	IP 30
Design :	Chain drive
Limit switch Open - Close :	with encoder
Signaling contact :	No
Stroke length can be shortened :	Ja
Humidity :	NOT suitable for outdoor use! max. 80% relF, NICHT KONDENSIEREND
Voltage :	230V AC
Modell :	C30
Color:	black
Stroke length:	200/380mm
Thrust:	300N
Scope of delivery:	Drive incl. bracket and accessories for top-hung and bottom-hung windows
Dimensions:	337.2x80x49 mm
Housing:	Plastic
Speed:	37mm/s
Current / Power:	0,26A
Tensile force:	300N

Scope of delivery & accessories more

Scope of delivery

Drive incl. bracket and accessories for top-hung and bottom-hung windows
