TOPP Chain drive C20 - 230V
230V, 300N, max. 360mm
9946
3A3#000000911
Ready to ship today, Delivery time appr. 1-3 workdays
Important info about the delivery time
€149.94 *
incl. VAT plus shipping costs
Leave your email address and stay informed about this article.
as soon as the item is back in stock
as soon as the item drops in price
as soon as the item is available as a special offer
Chain drive Topp model C20 in plastic housing, incl. bracket and accessories for top-hung and... more
Chain drive Topp model C20 in plastic housing, incl. bracket and accessories for top-hung and bottom-hung windows
Technical data
- Supply voltage: 230V ~ 50Hz
- Thrust force: 300 N
- Pulling force: 200 N
- Stroke (adjustable): 240 / 360 mm
- Power consumption: 0,12 A
- Speed: 8 mm\s
- Running time: 46 s
- Protection class: II (protective insulation)
- Operating mode: S2- 4 min
- Ambient temperature: - 5°C + 50°C
- Protection class: IP 30
- Parallel connection of 2 or more actuators: yes
- Limit switch open/close: electronic / load disconnection
- Dimensions: 362x48x34 mm
Technical advice
+49 9282 48731-15
technik@bsc-technology.de
Fast delivery
... of goods in stock. Orders placed before 14:00 are usually shipped the same day.
Questions about the article
Wir haben insgesamt 13 Kettenantriebe verschiedener Hersteller getestet und erstaunliche Unterschiede in der Lautstärke und im Laufgeräusch festgestellt.
Technical data more
| RWA suitable : | No |
| Application : | For bottom-hung windows (without restriction to 15cm), For skylight domes, For standard tilt and turn windows, Pivot window, Tilt window, Top hung window |
| Ambient temperature : | -5°C ...+50°C |
| Operating mode : | S2 - 4min |
| Protection class : | IP 30 |
| Design : | Chain drive |
| Limit switch Open - Close : | Electronically when opening, by current consumption when closing |
| Signaling contact : | No |
| Stroke length can be shortened : | Ja |
| Humidity : | NOT suitable for outdoor use! max. 80% relF, NICHT KONDENSIEREND |
| Voltage : | 230V AC |
| Modell : | C20 |
| Color: | black |
| Stroke length: | 240/360mm |
| Thrust: | 300N |
| Scope of delivery: | Drive incl. bracket and accessories for top-hung and bottom-hung windows |
| Dimensions: | 362x48x34mm |
| Housing: | Plastic |
| Speed: | 8mm/s |
| Current / Power: | 0,12A |
| Tensile force: | 200N |
Scope of delivery & accessories more
Scope of delivery
Drive incl. bracket and accessories for top-hung and bottom-hung windows
Accessories
Downloads more
Download Datenblatt C20 (EN)
